Heavy turbo gang assembly, Great plains mfg., inc – Great Plains 4000TT Operator Manual User Manual
Page 63

Great Plains Mfg., Inc.
Section 3: Replacement Parts
12/15/2004
Series I 1000TT - 4000TT Turbo-Till 586-043M
61
Heavy Turbo Gang Assembly
Ref. Kent No. GP Part No. Part Description
Comments
1.
586-182D
Gang Mount Bracket, 5/8
2.
807-229C
C-Shank Bearing Hanger, 1x3
3.
586-186D
Gang Bracket Mount
4.
812-006CP Casting Top Bearing
5.
822-026C
Bearing w/Rubber Boot CDS211TTR23N/3A
6.
586-187D
Casting Bottom Bearing Finished
7.
800-130C
Zerk Grease Straight 1/8-27MPT
8.
586-252D
Half Spool Cast TT
(S/N 2068NN+)
586-100H
Half Spool – Rock Package
(S/N 2067NN-)
9.
820-011C
20” Turbo Blade, .256 x 1.78 C
FC2130
820-261C
Coulter Turbo, 20 x .197 x 1.78
Optional (S/N 2068NN+)
10.
586-152D
Full Spool – TT 10” Cast
11.
586-124D
Gang Bolt, 45 1/2
5 Blade Gang @ 10” Space
586-086D
Gang Bolt, 55 1/2
6 Blade Gang @ 10” Space
586-087D
Gang Bolt, 65 1/2
7 Blade Gang @ 10” Space
586-095D
Gang Bolt, 75 1/2
8 Blade Gang @ 10” Space
12.
586-056D
Gang Washer 3/4 x 6 1/2
13.
FC2270 804-200C Washer
Dura-Tight 1.81ID x 7.0
14.
4228 804-205C
Machine
Washer, 1 3/4ID x 2 1/2OD 10GA
15.
803-339C
Slotted Hex Nut, 1 3/4
16.
802-842C
Hex Bolt, 1/4-20 x 3 1/4 Gr.8
805-358C
Pin Spirol, 1/4 x 2 1/2 Heavy
Changed to 802-842C
17.
586-099H
Scraper Bar Bracket, 5/8 x 3
18.
586-188D
Scraper Bar, 35
2 Scrapers @ 10” Space
586-189D
Scraper Bar, 45
3 Scrapers @ 10” Space
586-190D
Scraper Bar, 55
4 Scrapers @ 10” Space
586-191D
Scraper Bar, 65
5 Scrapers @ 10” Space
19.
586-090D
Scraper, 14 1/2
20.
586-093D
Scraper, 9 1/2
21. 111296
802-070C
Hex Bolt, 3/4-10 x 6
Requires Lock Nut item 31
802-360C
Hex Bolt, 3/4 x 6 1/2
22.
4112 804-023C
Lock
Washer,
3/4
23.
3012
803-027C
Hex Nut, 3/4
24.
802-095C
Hex Bolt, 3/4-10 x 7 Gr.5
25. 1110112
802-262C
Hex Bolt, 5/8 x 7 Gr.5
1110104
802-335C
Hex Bolt, 5/8 x 6 1/2
Changed to 802-262C
26.
4110 804-022C
Lock
Washer,
5/8
27.
3010
803-021C
Hex Nut, 5/8
28.
806-005C
U-bolt, 1/2 x 2 x 3
29.
4108 804-015C
Lock
Washer,
1/2
30.
3008
803-020C
Hex Nut, 1/2
31. 3112
803-026C
Lock Nut, 3/4
32.
804-075C
Flat Washer, 1/4
33.
803-255C
Nylon Lock Nut, 1/4-20
Legend: = 1st revision; = 2nd revision, = 3rd revision; use up existing stock;
⊗ not interchangeable; ⊗
Revision 2 is not interchangeable with 1
1/25/2008
