Appendix
Specifications and Capacities
Tire Inflation Chart
3N-4010F- 3N-4010HDF- 3N-4020F-
-4810 -6475 -4810 -6475 -4810 -6475
Operating Width 40 ft (12.2m)
Swath
a
a. All rows operating; for modified spacings, see “Row Spacing Data” on page 127.
480in (1219cm) 484in (1229cm) 480in (1219cm) 484in (1229cm) 480in (1219cm) 484in (1229cm)
Number of Rows 48 64 48 64 48 64
Row Spacing
Nominal
Swath Averaged
10in (25.4cm)
10in (25.4cm) 7.5in (19.1cm)
7.56in (19.2cm)
10in (25.4cm)
10in (25.4cm) 7.5in (19.1cm)
7.56in (19.2cm)
10in (25.4cm)
10in (25.4cm) 7.5in (19.1cm)
7.56in (19.2cm)
Tractor
Requirements
b
b. 7.5in row spacing, coulters, frame weights and markers increase power requirements over minimum.
275-400 hp (205-300 kW)
Seed Capacity 96 bu (3883 liters)
Drill Weight
c
c. Does not include markers, optional weights or seed. See “Typical Transport Weights” on page 26 and
“Frame Weight” on page 68.
26660 lbs
(12093 kg)
28260 lbs
(12819 kg)
27620 lbs
(12528 kg)
29540 lbs
(13399 kg)
29204 lbs
(13247 kg)
31652 lbs
(14357 kg)
Max. Additional 2000 lbs (907 kg)
Hydraulic Circuits 3 or 4 circuits required: load-sensitive or closed-center 15 to 30 gpm at 2250 psi
Transport Width 14 ft 10 1 ⁄
2
in (4.5 m)
Transport Height 8 ft (2.43 m) without markers, 12 ft 8 in (3.86 m) with markers
Transport
Clearance
13 1 ⁄
2
in (34.3 cm)
Operating Height 6ft 6 in (1.98 m) without markers, 11ft 2 in (3.40 m) with markers
Length 44 ft 4 in (13.51 m) folded, 32 ft 6 in (9.91 m) unfolded
Tire Sizes 395/55B16.5 NHS 12-Ply Skid Steer, on 8-Bolt rims
Tire Inflation Chart Tire Warranty Information
Tire Size Inflation All tires are warranted by the original manufacturer of the tire.
Tire warranty information is found online at the manufac-
turer’s websites listed below. For assistance or information,
contact your nearest Authorized Farm Tire Retailer.
ManufacturerWebsite
Firestone
www.firestoneag.com
Gleason www.gleasonwheel.com
Titan www.titan-intl.com
395/55B16.5 NHS
60 psi
414 kPa
