Great Plains 3N-4020 Operator Manual User Manual
Operator manual, Manufacturing, inc

Manufacturing, Inc.
© Copyright 2013
Printed 2013-10-29
196-359M
EN
ORIGINAL INSTRUCTIONS
Operator Manual
3N-4010F, 3N-4010HDF and 3N-4020F
3-Section 40-Foot No-Till Drills
Read the operator manual entirely. When you see this symbol, the
subsequent instructions and warnings are serious - follow without
exception. Your life and the lives of others depend on it!
Illustrations may show optional equipment not supplied with standard unit or may
depict similar models where a topic is identical.
20476
This manual is related to the following products:
