Introduction
Great Plains Manufacturing wants you to be satisfied
with any new machine delivered by the Great Plains
Trucking network. To ease the assembly task and pro-
duce a properly working machine, read this entire man-
ual before setting up new equipment.
Implements Covered
• 3N-4010HDA Air Drill Implement, when used with:
• ADC2350B “pull behind” Air Drill Cart.
Note: This model drill is not compatible with the
“pull between” ADC2350 cart, nor the
ADC1150, ADC2220 or ADC2250 carts.
Note: Do not commence assembly unless the cart is also
at hand. Some drill components are shipped with
the cart.
Pre-delivery includes hitching to the air cart. The cart is
intended to be towed by the drill, although either can be
towed alone
a
if necessary.
Document Family
167-085M ADC2350/2350B Operator Manual
167-085M ADC2350/2350B Parts Manual
167-085B ADC2350/2350B Seed Rate Manual
196-444M 3N-4010HDA Operator Manual
196-444P 3N-4010HDA Parts Manual
196-444Q 3N-4010HDA Pre-Delivery (this manual)
110011445 DICKEY-john Air Cart Operator
110011461 3N40 QUICKSTART GUIDE
Definitions
IMPORTANT !
Paragraphs in this format present a crucial point of
information related to the current topic.
Read and follow the directions to:
- remain safe and
- avoid serious damage to equipment.
Note: Paragraphs in this format provide useful informa-
tion related to the current topic.
“Left” and “Right” are facing in the
direction of machine travel. An orienta-
tion rose in the line art illustrations
shows the directions of: Up, Back, Left,
Down, Front, Right.
a. If the drill alone is towed on public roads, install a temporary Slow Moving Vehicle reflector.
Figure 1
Left/Right Notation
27031
L
R
U
D
F
B
L
R
to &
to
callouts identify components in the currently
referenced Figure or Figures.
to call-outs reference new parts from the lists
starting on page 39, and are consistent across
all pages. Descriptions match those on the
cartons, bags or item tags, as well the current
Parts Manual.
