Parts Lists
Parts lists do not include options.
Parts Supplied with Drill or Air Cart
Callout
Part
Number
Quantity
Description
196-444Q
1
3N4010HDA PRE-DELIVERY MANUAL
168-216H
6
DISTRIBUTION TOWER WELDMENT
168-314D
Installed
DIST. TOWER TOP CAP
168-362D
4
NTA35 DIST TOWER MOUNT
168-376K
1
30.5L-32 TIRE/27-10 BLT WHL RH
168-377K
1
30.5L-32 TIRE/27-10 BLT WHL LH
168-378K
1
21.5L-16.1 TIRE/18-8 BLT WL RH
168-379K
1
21.5L-16.1 TIRE/18-8 BLT WL LH
196-291H
4
40P WEIGHT BRACKET WLDMNT
196-439H
1
3N-40 PULL HITCH WELDMENT
196-923D
2
CENTER AIR TOWER MOUNT PLATE
196-925D
2
CENTER TOWER MOUNT BOLT PLATE
197-062D
4
WEIGHT BRACKET ADJ LEG
198-137D
16 or 22
PRESS WHEEL PIVOT TUBE
800-044C
2
SNAP RING EXT 1 1/2 SHAFT
800-180C
12
2 1/2 AIR HOSE BAND CLAMP
801-166C
Installed
SFCHMS 10-24 X 3/4
802-007C
2
HHCS 5/16-18X3/4 GR5
802-034C
2
HHCS 1/2-13X1 1/4 GR5
802-041C
8
HHCS 1/2-13X3 1/2 GR5
802-057C
8
HHCS 5/8-11X2 1/4 GR5
802-065C
6
HHCS 3/4-10X2 1/4 GR5
802-131C
Installed
HHCS 5/16-18X3 GR5
802-421C
16 or 22
HFS 1/2-13X3 3/4 GR5 SPTHD
803-008C
2
NUT HEX 5/16-18 PLT
803-020C
2
NUT HEX 1/2-13 PLT
803-021C
8
NUT HEX 5/8-11 PLT
803-027C
30
NUT HEX 3/4-10 PLT
803-084C
Installed
NUT HEX NYLOCK 5/16-18 PLT
803-169C
16 or 22
NUT HEX FLG. LOCK 1/2-13 PLT.
803-183C
20
NUT HEX FLANGE 3/4-16 PLT
803-268C
Installed
NUT HEX NYLOCK 10-24 PLT
803-347C
16
WHL NUT, SWIVEL FLG 5/8-18 UNF
804-009C
2
WASHER LOCK SPRING 5/16 PLT
804-010C
4
WASHER FLAT 5/16 USS PLT
804-015C
2
WASHER LOCK SPRING 1/2 PLT
804-019C
8
WASHER FLAT 5/8 USS PLT
804-022C
8
WASHER LOCK SPRING 5/8 PLT
804-023C
30
WASHER LOCK SPRING 3/4 PLT
804-024C
6
WASHER FLAT 3/4 USS PLT
