Great Plains Manufacturing, Inc.
Air Drill Pre-Delivery
25
10/10/2008
196-444Q
75. Select the two mid-wing 24 ft (7.32m) lengths of:
990-125R SEED HOSE 2 1/2 ID KANAFLEX
and four (4):
800-180C 2 1/2 AIR HOSE BAND CLAMP
Connect these to bulkhead ports
and
.
Route them to the mid-wing towers,
and
respectively. Route must pass through the hoops at
the wing pivots. Secure ends with clamps
.
76. Select the two outside 10 ft (3.05m) lengths of:
990-125R SEED HOSE 2 1/2 ID KANAFLEX
and four (4):
800-180C 2 1/2 AIR HOSE BAND CLAMP
Connect these to bulkhead ports
and
.
Route them to the center towers,
and
respec-
tively. Secure ends with clamps
.
Install Secondary Hoses
Secondary seed hose is 1 inch (2.5cm) in diameter and
is provisioned in 100-foot (30.5m) rolls. The raw hose is
cut-to-length to connect each distribution tower outlet
(port) to a row unit seed tube.
Port Numbering Convention
Tower ports are numbered:
1-8
on 3N-4010HDA-4810 or
1-11 on 3N-4010HDA-6675
Ports are numbered in ascending order, clockwise
around tower. Port one (1) is the port closest to the cen-
ter of the tower-mounting plate
. This corresponds to:
on wing towers (1, 2, 5, 6): rear-most port
on center towers (3, 4): port closest to drill center.
Note: If blockage detectors are to be installed, it is bene-
ficial to record the opener row number at each tow-
er port opening, using a permanent marker, on the
tower top cap.
Start with Tower 1 (left wing, left tower).
Refer to Figure 27 on page (shown exploded for clarity)
77. Loosen, but do not remove, four (4) nuts
holding
tower halves (
or
) together.
78. Locate Port 1
Figure 25
Terminate Primary Hose
27058
66
28
14
66
28
b
e
2
5
28
66
Figure 26
Tower Port Numbering
28185
16
1
PORT
PORT 2
PORT 8 or 11
28
a
f
3
4
28
Figure 27
Tower Cap Details
27058
43
60
58
57
57
58
16
43
57
58
