MUSICA KEYPAD DISPLAY SCREENS

All specifications subject to change without notification. All rights reserved. Copyright©2007 NetStreams

Main +1 512.977.9393 / fax +1 512.977.9398 / 3600 W. Parmer Lane Suite 100, Austin, TX 78727 /

www.netstreams.com


NS-0505-7121

22

4.9 Programming Macros

All Musica MU5066 keypads have the capability to program two individual macros per input source

to begin programming

:

1. Completely learn the IR codes into all source buttons on all four source pages (FM tuner excluded).
2. Select source S1 through S4 to build the macro for that device.
3. Push the menu button and scroll with the right arrow to the “IR” location on menu bar.
4. Scroll with the up arrow to “Macro 11” or “Macro 12”.
5. Scroll with the right arrow to highlight “Start
6. “Press a source button! For step 1” will appear on the LCD screen.
7. Press the desired source button (0 through 9) for step 1.
8. Press the desired source button (0 through 9) for step 2.
9. Press the desired source button (0 through 9) for step 3.
10. Press the desired source button (0 through 9) for step 4.
11. Macros can contain 2, 3, or 4 steps.


To exit macro programming mode, push the menu button or the arrow left button or wait for keypad to time-out
and return to the source display.

Time delays can be added to the steps which have been programmed. To do so:
1. Push the menu button and scroll with the right arrow to “IR” location on menu bar.
2. Scroll with up arrow to “Timing”.
3. Scroll with right arrow to enter the timing selection window. In this window you may select “500MSEC, 1
SEC, or 2 SEC”.
4. To make a selection, scroll with up arrow or down arrow to highlight the selection needed. This selection is
applied to all steps in Macro 1 and Macro 2 for this source. Each source can receive the time delay
necessary.

To exit the Timing programming mode, push the menu button or wait for keypad to time-out and return to the
source display.
