MUSICA KEYPAD DISPLAY SCREENS

All specifications subject to change without notification. All rights reserved. Copyright©2007 NetStreams

Main +1 512.977.9393 / fax +1 512.977.9398 / 3600 W. Parmer Lane Suite 100, Austin, TX 78727 /

www.netstreams.com


NS-0505-7121

14


Volume Up/Down in Basic Screen









Mute Function in Basic Screen









External AMP Mode View in Basic Screen

Displays the current level of volume with
graphical view

Shows the status of volume adjusting when pressing volume UP/DOWN

Shows that MUTE is activated.

Displays the current state of volume. Stops the
output of the audio signals and Audio Level
Meter.

EXT is displayed when an external audio source
connected to the Audio Port is selected for
playback and you have selected the EXT source.
