XAP Net — Appendix

23

XAP Net — Appendix

22

Technical Services Group ~ 1-800-283-5936 (USA) ~ 1-801-974-3760

Technical Services Group ~ 1-800-283-5936 (USA) ~ 1-801-974-3760

Pinouts

RS-232 Control port (female)

Pin Number

Control

Pin Number

Control

1

DCD

6

DSR

2

TXD

7

CTS

3

RXD

8

RTS

4

DTR

9

NA

5

Ground

RS-232 To XAP port (male)

Pin Number

Control

Pin Number

Control

1

DCD

6

DSR

2

RXD

7

RTS

3

TXD

8

CTS

4

DTR

9

NA

5

Ground

Ethernet RJ-45 connector

Pin Number

Control

Pin Number

Control

1

TX+

5

Not used

2

TX -

6

RX -

3

RX +

7

Not used

4

Not used

8

Not used

Compliance

FCC Part 15/ICES-003 Compliance

This equipment has been tested and found to comply with the limits for a Class A digital device, pur-
suant to Part 15 of the FCC rules and Industry Canada ICES-003.These limits are designed to pro-
vide reasonable protection against harmful interference when the equipment is operated in a commer-
cial environment.This equipment generates, uses, and can radiate radio frequency energy and, if not
installed and used in accordance with the instruction manual, may cause harmful interference to radio
communications. Operation of this equipment in a residential area is likely to cause harmful interfer-
ence, in which case the user will be required to correct the interference at his/her own expense.

Operation is subject to the following two conditions: (1) This device may not cause interference, and
(2) This device must accept any interference including interference that may cause undesired opera-
tion of the device.

Changes or modifications not expressly approved by ClearOne Communications could void the user's
authority to operate the equipment.

European Compliance

This equipment has been approved in accordance with Council Directive 1999/5/EC "Radio
Equipment and Telecommunications Equipment" Compliance of the equipment with the Directive is
attested by the application of the CE mark on the equipment.

EC Declaration of Conformity

Application of Council Directive(s):

1999/5/EC Radio equipment and Telecommunications
Terminal Equipment (R&TTE) Directive

Manufacturer's Name:

ClearOne Communications

Manufacturer's Address:

1825 West Research Way
Salt Lake City, Utah 84119 U.S.A.

Model No.:

XAP Net (910-151-150)

Standard(s) to which Conformity is declared:

89/336/EEC "Electromagnetic Compatibility (EMC) Directive":

EN 55022: 1994 (Emissions)

Specification for limits and methods of measurement of
radio interference characteristics of information
technology equipment.

EN 61000-3-2:2000

Part 3: Limits - Section 2: Limits for harmonic current
emissions.

EN 61000-3-3:1996

Section 3: Limitation of voltage fluctuations and flicker
in low voltage supply systems for equipment with rated
current up to and including 16 A.

EN 55024: 1998 (Immunity)

Information technology equipment - Immunity
characteristics - Limits and methods of measurement.

EN 61000-4-2: 2001

Electrostatic Discharge

EN 61000-4-3: 2001

Radiated RF Immunity

EN 61000-4-4: 2001

Electrical Fast Transients

EN 61000-4-5: 2001

Lightning Surge

EN 61000-4-6: 2001

Conducted RF Immunity

EN 61000-4-11: 2001

Voltage Dips and Voltage Interruptions

73/23/EEC "Low Voltage Directive (LVD)":
IEC/EN 60950: 1999

Safety of Information Technology Equipment, Electrical
Business Equipment
