Chapter
5
Learning IR
This chapter discusses the following:
Adjusting the IR Frequency
Learning IR for Control of Sources
Creating Macros
You learn IR from the SOURCES menu ->S1, S2, S3, or S4 selected.
Adjusting the IR Type
The IR TYPE setting sets the IR frequency to 38 or 56 KHz and if the source uses
alternating codes.
To set the IR frequency, follow these steps:
1.
Use the down arrow key to highlight IR TYPE.
2.
Press the MENU key to select IR TYPE.
3.
Use the down arrow key to highlight MODIFY and press the MENU key. The
following screen appears:
Figure 5-1
Setting the IR frequency
4.
Press the right or left arrow key to switch between 38 and 56 KHz.
5.
Select the down arrow to select 1-CODE.
6.
Use the right or left arrow key to select 1-CODE or 2-CODE for alternating IR
code.
