Key Features, Components, and Specifications
2-3
All specifications subject to change without notification. All rights reserved. Copyright © 2007 NetStreams
Main +1 512.977-9393 / fax +1 512.977.9398 / Toll Free Technical Support +1 866-353-3496
3600 W. Parmer Lane, Suite 100; Austin, TX 7872
Figure 2-1
Quartet Front Panel
Figure 2-2
Quartet Rear Panel
1.
IR receiver - receives IR signals from the Quartet remote or a universal remote
(sold separately) (front panel)
2.
Display - shows the four sources and what is playing on them, displays the FM
channel selected and antenna strength, and provides access to the Quartet main
menu (front panel)
3.
IR Emitter/Output connectors for four sources (rear panel)
1.IR Receiver
2. Display
3. IR Emitter Output Connectors for 4 Sources
4. 4 RCA Connectors for
5. Common IR Emitter/Output Connector
6. FM Antenna Connector
7. 4 Quartet Keypad Connectors
8.4-pin Phoenix
9. AC Power
Connector
10. MRP Power
Switch
Connectors for Speakers
sources
