1130 series, Non hold open door closers — parallel arm – SARGENT 1130 Series User Manual
Page 3
Parts
Right Hand Shown
2
1
Non Hold Open Door Closers — Parallel Arm
3
4
Door
Opening
To 100°
101° to 130°
131° to 180°
*
A
9-1/4
(235)
7-3/4
(197)
5-3/4
(146)
B
7-5/8
(194)
6-1/8
(156)
4-1/8
(105)
2-3/4
(70)
3/8
(10)
1/2
(13)
7/16
(11)
2
(50)
A
3-1/4
(83)
3/4
(19)
9-1/16
(230)
CL
B
Top of
Door
Door/Wall/Hardware/Jamb
*
conditions permitting
Inches
(mm)
5
— 3 —
S
L
Place Arm on
Spindle
Rotate
Remove Arm
from Spindle
Close Valves
L
S
Latch
Sweep
Optional
Co
ver
See Step 6 on Page 4
Frame
Slower
-
Slower
-
80-9311-0001-021 (12-12)
1130 Series
A7674B
Copyright © 2012, SARGENT Manufacturing. All rights reserved. Reproduction in whole or in
part without the express written permission of SARGENT Manufacturing is prohibited.
