Page 26

8-22

Quick Robotic toRch

SM-QRTORCH

REPLACEMENT PARTS

*** Standard On All QR Series Torch Body and Cable Assemblies

QRW & QRWS Series Replacement Parts (cont.)

Item No.

Part No.

Stock No.

Description

---

Purge Hose Assembly (Includes Hose Plug Nipple & Hose Clamp)

QR03-PH

3045-1200

For use with 3ft. (91cm) torch

QR035-PH

3045-1201

For use with 3.5ft. (1,07m) torch

QR04-PH

3045-1202

For use with 4ft. ( 1,22m) torch

QR045-PH

3045-1203

For use with 4.5ft. (1,37m) torch

QR05-PH

3045-1204

For use with 5ft. (1,52m) torch

QR055-PH

3045-1205

For use with 5.5ft. (1,68m) torch

QR06-PH

3045-1206

For use with 6ft. (1,83m) torch

QR07-PH

3045-1207

For use with 7ft. (2,13m) torch

QR08-PH

3045-1208

For use with 8ft. (2,44m) torch

QR10-PH

3045-1209

For use with 10ft. (3m) torch

QR12-PH

3045-1210

For use with 12ft. (4m) torch

QR15-PH

3045-1211

For use with 15ft. (5m) torch

QRW00-WO

3045-1262

Water-Out Hose Assy - (Includes Hose Clamp) – For All Torches

---

Water-In Hose Assembly (Includes Hose Clamp)

QRW03-WI

3045-1275

For use with 3ft. (91cm) torch

QRW035-WI

3045-1276

For use with 3.5ft. (1,07m) torch

QRW04-WI

3045-1277

For use with 4ft. ( 1,22m) torch

QRW045-WI

3045-1278

For use with 4.5ft. (1,37m) torch

QRW05-WI

3045-1279

For use with 5ft. (1,52m) torch

QRW055-WI

3045-1280

For use with 5.5ft. (1,68m) torch

QRW06-WI

3045-1281

For use with 6ft. (1,83m) torch

QRW07-WI

3045-1282

For use with 7ft. (2,13m) torch

QRW08-WI

3045-1283

For use with 8ft. (2,44m) torch

QRW10-WI

3045-1284

For use with 10ft. (3m) torch

QRW12-WI

3045-1285

For use with 12ft. (4m) torch

QRW15-WI

3045-1286

For use with 15ft. (5m) torch

---

Cable Cover Kit

QR03-CV

3045-1213

For use with 3ft. (91cm) torch

QR035-CV

3045-1214

For use with 3.5ft. (1,07m) torch

QR04-CV

3045-1215

For use with 4ft. ( 1,22m) torch

QR045-CV

3045-1216

For use with 4.5ft. (1,37m) torch

QR05-CV

3045-1217

For use with 5ft. (1,52m) torch

QR055-CV

3045-1218

For use with 5.5ft. (1,68m) torch

QR06-CV

3045-1219

For use with 6ft. (1,83m) torch

QR07-CV

3045-1220

For use with 7ft. (2,13m) torch

QR08-CV

3045-1221

For use with 8ft. (2,44m) torch

QR10-CV

3045-1222

For use with 10ft. (3m) torch

QR12-CV

3045-1223

For use with 12ft. (4m) torch

QR15-CV

3045-1224

For use with 15ft. (5m) torch
