Quick Robotic toRch

SM-QRTORCH

REPLACEMENT PARTS

QRA & QRAS Series Replacement Parts (cont.)

*** Standard On All QR Series Torch Body and Cable Assemblies

Item No.

Part No.

Stock No.

Description

---

Outer Cover Assembly (Includes Nylon Cable Tie – 2 ea.)

QR03-LC

3045-1226

For use with 3ft. (91cm) torch

QR035-LC

3045-1227

For use with 3.5ft. (1,07m) torch

QR04-LC

3045-1228

For use with 4ft. ( 1,22m) torch

QR045-LC

3045-1229

For use with 4.5ft. (1,37m) torch

QR05-LC

3045-1230

For use with 5ft. (1,52m) torch

QR055-LC

3045-1231

For use with 5.5ft. (1,68m) torch

QR06-LC

3045-1232

For use with 6ft. (1,83m) torch

QR07-LC

3045-1233

For use with 7ft. (2,13m) torch

QR08-LC

3045-1234

For use with 8ft. (2,44m) torch

QR10-LC

3045-1235

For use with 10ft. (3m) torch

QR12-LC

3045-1236

For use with 12ft. (4m) torch

QR15-LC

3045-1237

For use with 15ft. (5m) torch

QR-RC

3045-1238

Rear Spring Cap

QRA-CS

3045-1239

Rear Case Assembly

R176MH

2060-2184

Miller

Connector Plug (Includes Items #16 & 17) - ***

R174MH

2035-2109

Miller

Connector Plug (Includes Items #16 & #17)

R175M-N045

2050-2181

Miller

Plug Nipple, .045” (1,0mm) Wire (Use w/R176MH) - ***

R174M-N045

2040-2192

Miller

Plug Nipple, .045” (1,0mm) Wire (Use w/R174MH)

R175M-N116

2050-2182

Miller

Plug Nipple, .062” (1,6mm) Wire (Use w/R176MH) - ***

R174M-N116

2040-2191

Miller

Plug Nipple, .062” (1,6mm) Wire (Use w/R174MH)

176S-H

2060-2177

Tweco

Connector Plug - ***

350-174H

2035-2110

Tweco

Connector Plug (Uses R44 series Conduit)

350-174PH

2035-2172

Panasonic

Connector Plug (Uses R44 series Conduit )

QTR176LH

2086-2624

Lincoln

Connector Plug (2.71” – 68,83mm OAL.) - ***

EL176LH

2060-2680

Lincoln

Connector Plug (3.84” – 97,54mm OAL)

QTR174LH

2086-2623

Lincoln

Connector Plug (Uses R44 series Conduit)

---

XQRA Power Cable Assy (Includes Hose Clamps)

XQR603-CH

3045-1375

For use with 3ft. (91cm) torch

XQR6035-CH

3045-1376

For use with 3.5ft. (1,07m) torch

XQR604-CH

3045-1377

For use with 4ft. ( 1,22m) torch

XQR6045-CH

3045-1378

For use with 4.5ft. (1,37m) torch

XQR605-CH

3045-1379

For use with 5ft. (1,52m) torch

XQR6055-CH

3045-1380

For use with 5.5ft. (1,68m) torch

XQR606-CH

3045-1381

For use with 6ft. (1,83m) torch

XQR607-CH

3045-1382

For use with 7ft. (2,13m) torch

XQR608-CH

3045-1383

For use with 8ft. (2,44m) torch

XQR610-CH

3045-1384

For use with 10ft. (3m) torch

XQR612-CH

3045-1385

For use with 12ft. (4m) torch

XQR615-CH

3045-1386

For use with 15ft. (5m) torch

XQRA-CS

3045-1240

Rear Case Assembly (Includes Item “C”)

174X-2S

2040-2177

Euro-Kwik Nut
