tekmar 541 Thermostat - Manual (Page 9)

9 of 24 © 2007 D 541 - 08/07
Item Field Range Access Description
NONE,
MBR1, MBR2,
MBR3, MBR4
Default = NONE
USER
INST
ADV
HEAT SCHEDULE SECTION H
If a schedule is not required, select NONE.
If the schedule is set on another thermostat, select
MBR1 to MBR4.
Note: This item can be viewed in the USER and
INST access levels but can only be adjusted in the
ADV access level.
Schedule Menu (1 of 1)
The Schedule menu items set the schedule type, the
number of events per day, and the event times.
SC
HEDULE MENU
Item Field Range Access Description
SEC, LTD, USER,
INST, ADV
Default = USER
SEC
LTD
USER
INST
ADV
ACCESS LEVEL
The access level of the thermostat. The access column
shows which items are visible in each access level.
Note: This item is only available when the Lock / Unlock
DIP switch on the thermostat and the tN4 system
control are set to Unlock.
°F, °C
Default = °F
USER
INST
ADV
UNITS SECTION M
Select Fahrenheit or Celsius as the temperature
units.
ON, TMPY, OFF
Default = TMPY
USER
INST
ADV
BACKLIGHT SECTION N
Select whether the backlight displays permanently,
temporarily, or is off. The temporary backlight lasts
for 30 seconds.
Misc (Miscellaneous) Menu (1 of 2)
The Miscellaneous menu items set display and control
options such as access level and temperature units.
Continued on next page.
MISC MENU
After the last item, the control returns to the first item in the menu.
