© 2007 D 541 - 08/07 8 of 24
Item Field Range Access Description
Occ, Away,
PERM1, Away 2
PERM UnOcc 3,
PERM 4, PERM 5
TMPY Occ 6
TMPY 7, TMPY 8
Default = PERM 1
USER
INST
ADV
SELECT SECTION J
Select the scene for the building.
Note: Only Occ and AWAY are available when no
schedule is selected.
Schd
Wake
Occ
UnOcc
Sleep
Away
Default = SCHD
INST
ADV
SET PERMANENT 1 SECTION J
Select an action for the Permanent 1 scene.
Note: This item is only available when SCENE menu
is set to ON and a schedule has been selected.
Schd
Wake
Occ
UnOcc
Sleep
Away
Default = SCHD
INST
ADV
SET PERMANENT 4 SECTION J
Select an action for the Permanent 4 scene.
Note: This item is only available when SCENE menu
is set to ON and a schedule has been selected.
Schd
Wake
Occ
UnOcc
Sleep
Away
Default = SCHD
INST
ADV
SET PERMANENT 5 SECTION J
Select an action for the Permanent 5 scene.
Note: This item is only available when SCENE menu
is set to ON and a schedule has been selected.
Schd
Wake
Occ
UnOcc
Sleep
Away
Default = SCHD
INST
ADV
SET TEMPORARY 7 SECTION J
Select an action for the Temporary 7 scene. The
scene lasts for 4 hours before reverting to the previous
permanent scene.
Note: This item is only available when SCENE menu
is set to ON and a schedule has been selected.
Schd
Wake
Occ
UnOcc
Sleep
Away
Default = SCHD
INST
ADV
SET TEMPORARY 8 SECTION J
Select an action for the Temporary 8 scene. The
scene lasts for 8 hours before reverting to the previous
permanent scene.
Note: This item is only available when SCENE menu
is set to ON and a schedule has been selected.
OFF, ON
Default = OFF
INST
ADV
SCENE MENU SECTION J
Select the Scene feature of the thermostat.
Scene Menu (1 of 1)
The Scene Menu items set the current scene as
well as the scene settings.
SCENE MENU
After the last item, the control returns to the first item in the menu.
