2. INSTALLATION PROCEDURE

Use this section to properly unpack, set into place, and prepare DIGICOIL for set up.

Inspect the shipping container for any visible damage while the trucking company is still there. If
you see any damage, immediately file a damage claim with that trucking company. Otherwise you
may be responsible for any needed repairs.

1. Unpacking

1) Remove wood screws on top of crate to remove crate top.

2) Remove front of crate and either adjacent side of crate also fastened by wood screws.
3) Use a 5/8” Allen wrench to remove the bolts holding the DIGICOIL to the pallet. The

bolts are located near the casters.

4) Slide the DIGICOIL off the pallet and onto the floor.

2. Locate foot pedal secured to the shipping skid. Hook up air tube for the foot pedal into

fixture located underneath machine at opposite end of the control panel.

3. Slide on paper jogging tray with binding element size guide to front cover near the control

panel using the two t-slot holes.

4. Slide on output tray using the four t-slot holes onto the output end of the machine.
5. Locate the spine formers that are bolted together and packaged in a separate box. Unpack

and place the Spine Formers on the holder inside the machine.

6. Have your electrician hook up the appropriate power requirements listed in the specifications

section of this manual. CAUTION: DO NOT APPLY POWER TO THE
DIGICOIL!! A GBC technician will check to insure proper power is present when
installation is scheduled. YOU WILL VOID YOUR WARRANTY IF YOU APPLY
POWER.

7. Be sure that you have COLOR COIL SUPPLIES and enough pre-punched books to run your

machine for at least one hour. Please contact your sales representative if you have any supply
needs.

8. Contact GBC National service to schedule a technician to complete your installation.
