1. SPECIFICATIONS

Use this section to determine proper installation requirements as well as the capabilities of the DIGICOIL.

Sheet Size:

4.25” x 5” to 14.5” x 12”

108mm x 127mm to 368.3mm x 304.8mm

Holes:

Holes in paper should be made with a 4:1, 0.2475
pitch, over-sized oval -shaped punching tool ONLY

Coil Size:

From 8mm diameter up to 33mm diameter 4:1 GBC
Plastic Coil

Coil Length:

From 5” (127mm) to 16.25” (412.75mm)

Productivity:

10mm coil - up to 450 documents per hour
30mm coil – up to 250 documents per hour
(Times depend on element length, document
punching quality, but most importantly operator
proficiency)

Machine Weight:

275lbs. (125kg) est.

Dimensions:

48”D x 48”W x 60”H
121.92cm x 121.92cm x 152.4cm

Electrical Power:

115V AC, 60Hz, 4 amps, 480 Watts

Short Circuit Interrupt Capacity:

2000A

Ambient Air Temperature:

- 40

Humidity Rating:

30% - 95% (non-condensing)

Year of Manufacture:

2000
