E-flite Sobré 3D Profile Assembly Manual
 4. The struts should extend roughly 3 /
32
-inch (2.5mm)
through the top of the wing. This will give the landing
gear support disks plenty of strut to attach to.
Hint: You can just drop the disks into position and check
to make sure the strut extends beyond the disk instead of
measuring it.
 5. Check that the wheels are parallel or have slight
toe-in. Use foam-compatible CA to glue the struts to
the fuselage and each other. Make sure the wing is
sitting parallel to the ground so the wheels are located
at the same height.
 6. Install the landing gear support disks using foam-
compatible CA. Make sure to glue the disks securely
to both the horizontal fuselage and landing gear
struts.
 7. Use foam-compatible CA to glue the wheel pants
to the wheel retainers. Make sure the pants are
positioned so they won’t drag on the ground during
takeoff and landing before applying the CA.
