System Specification Tables (continued)
CHART 4: W110 Series Backwashing Greensand Plus Filters With SXT Timers
MODEL NO.
VALVE
PIPE SIZE
(IN.)
TANK
SIZE
MEDIA
(CU. FT.)
PEAK SERVICE
FLOW (GPM)
BACKWASH
(GPM)
FLOOR SPACE
(L x W x H).
SHIP WT.
(LBS.)
NGP09-W110
W110
1
9 x 48
1
3
5
16 x 21 x 55
137
NGP10-W110
W110
1
10 x 54
1.5
4
7
16 x 22 x 62
190
NGP12-W110
W110
1
12 x 52
2
5
10
17 x 24 x 60
258
NGP14-W110
W110
1
14 x 65
3
6
12
18 x 33 x 74
370
CHART 5: W110 Series Backwashing Carbon Filters With SXT Timers
MODEL NO.
VALVE
PIPE SIZE
(IN.)
TANK
SIZE
MEDIA
(CU. FT.)
PEAK SERVICE
FLOW (GPM)
BACKWASH
(GPM)
FLOOR SPACE
(L x W x H).
SHIP WT.
(LBS.)
NC09-W110
W110
1
9 x 48
1
4
4
16 x 10 x 55
80
NC10-W110
W110
1
10 x 54
1.5
6
5
16 x 11 x 62
105
NC12-W110
W110
1
12 x 52
2
8
7
17 x 13 x 60
145
NC14-W110
W110
1
14 x 65
3
11
10
18 x 15 x 74
200
NC16-W110
W110
1
16 x 65
4
14
12
20 x 17 x 74
265
CHART 6: W110 Series Backwashing Empty Filters With SXT Timers
MODEL NO.
VALVE
PIPE SIZE
(IN.)
TANK
SIZE
MEDIA
(CU. FT.)
PEAK SERVICE
FLOW (GPM)
BACKWASH
(GPM)
FLOOR SPACE
(L x W x H).
SHIP WT.
(LBS.)
NX09-W110
W110
1
9 x 48
1
10
5
16 x 10 x 55
53
NX10-W110
W110
1
10 x 54
1.5
10
7
16 x 11 x 62
64
NX12-W110
W110
1
12 x 52
2
20
10
17 x 13 x 60
90
NX14-W110
W110
1
14 x 65
3
40
12
18 x 15 x 74
118
NX16-W110
W110
1
16 x 65
4
50
20
20 x 17 x 74
155
3 W110 LXT Downflow Softeners and SXT Filters
