System Specification Tables
NOTE: All softeners use LXT timers and all filters use SXT timers. Maximum or peak flow rates are not to be interpreted as
continuous flow capabilities.
CHART 1: W110 Series Metered Water Softeners Water With LXT Timers
MODEL NO.
CAPACITY
(MAX.)
PIPE SIZE
(IN.)
MINERAL TANK BRINE TANK FLOW RATE & PRESSURE
SHIP WT.
(LBS.) TANK
SIZE
RESIN
FT 3
TANK
SIZE
SALT
FILL
SERVICE
(GPM)
DROP
(PSI)
BKW
(GPM)
M3011-W110 30,000 1 9 x 48 1 18 x 40 400 12 15 2 110
M3013-W110 45,000 1 10 x 54 1.5 18 x 40 400 12 15 2.4 130
M3015-W110 60,000 1 12 x 52 2 18 x 40 400 13 15 3.5 190
M3017-W110 90,000 1 14 x 65 3 18 x 40 400 14 15 5 230
M3019-W110 120,000 1 16 x 65 4 18 x 40 400 15 15 7 310
NOTE: Brine tanks come with safety float valve.
CHART 2: W110 Series Backwashing Micro Z Filters With SXT Timers
MODEL NO. VALVE
PIPE SIZE
(IN.)
TANK
SIZE
MEDIA
(CU. FT.)
PEAK SERVICE
FLOW (GPM)
BACKWASH
(GPM)
FLOOR SPACE
(L x W x H).
SHIP WT.
(LBS.)
NM09-W110 W110 1 9 x 48 1 9 7 16 x 10 x 55 110
NM10-W110 W110 1 10 x 54 1.5 10 7 16 x 11 x 62 140
NM12-W110 W110 1 12 x 52 2 15 12 17 x 13 x 60 200
NM14-W110 W110 1 14 x 65 3 21 15 18 x 15 x 74 310
CHART 3: W110 Series Backwashing Filox Filters With SXT Timers
MODEL NO. VALVE
PIPE SIZE
(IN.)
TANK
SIZE
MEDIA
(CU. FT.)
PEAK SERVICE
FLOW (GPM)
BACKWASH
(GPM)
FLOOR SPACE
(L x W x H).
SHIP WT.
(LBS.)
NF09-W110 W110 1 9 x 48 1 6 7 16 x 10 x 55 167
NF10-W110 W110 1 10 x 54 1.5 9 7 16 x 11 x 62 235
NF12-W110 W110 1 12 x 52 2 12 12 17 x 13 x 60 318
NF14-W110 W110 1 14 x 65 3 18 15 18 x 15 x 74 460
W110 LXT Downflow Softeners and SXT Filters 2
