Master Programming Mode Chart

SXT

Before entering Master Programming, please contact your local

professional water dealer .

Master Programming Options

Abbreviation

Parameter

Option Abbreviation

Options

DF

Display Format

GAL

Gallons

Ltr

Liters

VT

Valve Type

5800

W110 Control Valve

RF

Regenerant Flow

dF1b

Standard Downflow Single Backwash

dF2b

Standard Downflow Double Backwash

Fltr

Filter

AIO

Air Injection Oxidizer

dFFF

Downflow Fill First

UFbd

Upflow Brine First

UFFF

Upflow Fill First

Othr

Other

CT

Control Type

Fd

Meter (Flow) Delayed

FI

Meter (Flow) Immediate

tc

Time Clock

dAY

Day of Week

C

Unit Capacity

Unit Capacity (Grains)

H

Feedwater Hardness

Hardness of Inlet Water (Grains)

RS

Reserve Selection

SF

Percentage Safety Factor

rc

Fixed Reserve Capacity

SF

Safety Factor

Percentage of the system capacity to be used as a reserve

RC

Fixed Reserve Capacity

Fixed volume to be used as reserve

DO

Day Override

The system's day override setting

RT

Regen Time

The time of day the system will regenerate

BW, BD, RR, BF

Regen Cycle Step Times

The time duration for each regeneration step. Adjustable from OFF and 0-199

minutes.
NOTE: If "Othr" is chosen under "Valve Type", then C1, C2, ...,

C20 will be displayed along with available cycle steps

RR, BD, SR, BW, RF, SP. LC denotes the Last Cycle.

D1, D2, D3, D4, D5,

D6, & D7

Day of Week Settings

Regeneration setting (On or Off) for each day of the week on day-of-week systems.

CD

Current Day

The Current day of the week

FM

Flow Meter Type

P0.7

3/4" Paddle Wheel Meter

t0.7

3/4" Turbine Meter

P1.0

1" Paddle Wheel Meter

t1.0

1" Turbine Meter

P1.5

1.5" Paddle Wheel Meter

t1.5

1.5" Turbine Meter

P2.0

2" Paddle Wheel Meter

Gen

Generic or Other non-Fleck Meter

K

Meter Pulse Setting

Meter pulses per gallon for generic/other flow meter

Some items may not be shown depending on timer

configuration. The timer will discard any changes and exit

Master Programming Mode if any button is not pressed for 5

minutes.

CAUTION

!

W110 LXT Downflow Softeners and SXT Filters
