EZ-LIGHT
™
–
for EZ-SCREEN
®
WARRANTY: Banner Engineering Corp. warrants its products to be free from defects for one year. Banner Engineering Corp. will repair or replace, free of charge, any
product of its manufacture found to be defective at the time it is returned to the factory during the warranty period. This warranty does not cover damage or liability for the
improper application of Banner products. This warranty is in lieu of any other warranty either expressed or implied.
P/N 121901 rev. E
Additional information on this product is immediately available online at
www.bannerengineering.com/121901
For further assistance, contact a Banner Engineering Applications Engineer at (763) 544-3164 or (888) 373-6767.
Accessory Mounting Brackets
SMB18A
• For use with M18 and T18 models or
base-mount T30 models
• 12-gauge, stainless steel, right-angle
bracket, curved mounting slot for
adjustable orientation
• Clearance for M4 (#8) hardware
Other
available
18 mm dia.
brackets:
SMB1815SF
SMB18Q
SMB18SF
SMB312PD
SMBAMS18RA
SMBAMS18P
SMB22A
• For use with base-mount K30L models
• 12-gauge, stainless steel, right-angle
bracket, curved mounting slot for
adjustable orientation
• Clearance for M4 (#8) hardware
SMB30A
• For use with T30 models or base-mount
K50L models
• 30 mm 12-gauge, 304 stainless steel,
right-angle mounting bracket, curved
mounting slot for adjustable orientation
• Clearance for M5 (#10) hardware
Other
available
30 mm dia.
brackets:
SMBAMS30RA
SMBAMS30P
SMB30SC
SMB30SC
SMB30MM
SMB3018SC
SMBDX80D
• DIN-mount bracket for K80L models
• Hardware included to mount to K80L
housing
• ABS
* K50FL models include a 48 mm (1.9") circular velcro mounting kit for easy mounting with no additional hardware
