EZ-LIGHT
™
–
for EZ-SCREEN
®
2
P/N 121901 rev. E
Banner Engineering Corp.
•
Minneapolis, MN U.S.A.
www.bannerengineering.com • Tel: 763.544.3164
60.0
[2.36"]
35.0
[1.38"]
16.0 [0.63"]
40.0 [1.58"]
2x 5.0 [0.20"]
2x 5.0 [0.20"]
2x 5.5 [0.21"]
Ø50 [1.97"]
17.0 [0.67"]
44.6 [1.76"]
K50FL Models
Ø 15 mm
(0.59")
M18 x 1
Thread
33.0 mm
(1.3")
53.6 mm
(2.11")
M12 X 1
M30 x 1.5
Thread
Ø 40.0 mm
(1.57")
45.0 mm
(1.77")
63.7 mm
(2.51")
Ø 15 mm
(0.59")
M12 X 1
30 mm
(1.2")
23 mm
(0.9")
Ø16.5 mm
(0.65")
61 mm
(2.4")
M12 X 1
M18 X 1
M18 Models
T18 Models
T30 Models
50.0 mm
(1.97")
38 mm (1.50")*
20 mm (0.79")
11 mm (0.43")
M30x1
(mounting nut
included)
Internal Threads
½ - 14 NPSM
Max. Torque 2.25 Nm
(20 in–lbf)
K50L Models
Supply Voltage and Current
K30L, M18 and T18 Models: +24V dc @ 30 mA max.
T30, K50L, K50FL and K80L Models: +24V dc @ 45 mA max.
Indicators
Entire translucent diffuser or dome provides indication. Red/Green indication
follows EZ-SCREEN OFF/ON OSSD#1 output.
Environmental Rating
IEC IP67
K80L has encapsulated electronics only; other models fully encapsulated
Connections
8-pin M12/Euro-style integral QD
Operating Conditions
Temperature: –40° to +50° C (–40° to +122° F)
Specifications
Dimensions
K80L Models
109.5 mm
(4.31")
80.8 mm
(3.18")
66.3 mm
(2.61")
26.0 mm
(1.02")
M12 X 1
65.0 mm
(2.56")
65.0 mm
(2.56")
4X 8–32 UNC
Max. Torque 1.12 Nm (10 in–lbf)
4X Ø 5.5 mm (Ø 0.22")
Max. Torque 1.12 Nm (10 in–lbf)
with supplied screws
Internal Threads ½ - 14 NPSM
Max. Torque 2.25 Nm (20 in–lbf)
31.0 mm
(1.22")
58.0 mm
(2.28")
30.0 mm (1.18")
16.0 mm (0.63")
M12 X 1
M22 X 1.5
K30L Models
