Page 6
I/O
Modbus Holding Register
I/O Type
Units
I/O Range
Holding Register
Representation
Terminal
Block Labels
Gateway or
DX85
Any Node
Min. Val-
ue
Max. Val-
ue
Min.
(Dec.)
Max.
(Dec.)
5
5
5 + (Node# × 16)
Analog IN 1
mA
V
0.0
0.0
20.0
10.0
0
65535
AI1
6
6
6 + (Node# × 16)
Analog IN 2
mA
V
0.0
0.0
20.0
10.0
0
65535
AI2
7
7
7 + (Node# × 16)
Reserved
8
8
8 + (Node# × 16)
Device Message
9
9
9 + (Node# × 16)
Discrete OUT 1
-
0
1
0
1
DO1
10
10
10 + (Node# × 16)
Discrete OUT 2
-
0
1
0
1
DO2
11
11
11 + (Node# × 16)
Discrete OUT 3
-
0
1
0
1
DO3
12
12
12 + (Node# × 16)
Discrete OUT 4
-
0
1
0
1
DO4
13
13
13 + (Node# × 16)
Analog OUT 1
mA
V
0.0
0.0
20.0
10.0
0
65535
AO1
14
14
14 + (Node# × 16)
Analog OUT 2
mA
V
0.0
0.0
20.0
10.0
0
65535
AO2
15
15
15 + (Node# × 16)
Control Message
16
16
16 + (Node# × 16)
Reserved
Some analog I/O models may use milliamps or voltage, depending on the model. Check the models table (on page 1) of your product's
data sheet to determine which model you have.
Specifications
Radio and General
Range
900 MHz: Up to 4.8 kilometers (3 miles)
2.4 GHz: Up to 3.2 kilometers (2 miles)
Transmit Power
900 MHz: 21 dBm conducted
2.4 GHz: 18 dBm conducted, less than or equal to 20
dBm EIRP
900 MHz Compliance (150 mW Radios)
FCC ID TGUDX80 - This device complies with FCC
Part 15, Subpart C, 15.247
IC: 7044A-DX8009
2.4 GHz Compliance
FCC ID UE300DX80-2400 - This device complies with
FCC Part 15, Subpart C, 15.247
ETSI/EN: In accordance with EN 300 328: V1.7.1
(2006-05)
IC: 7044A-DX8024
Spread Spectrum Technology
FHSS (Frequency Hopping Spread Spectrum)
Power
Requirements: +10 to 30V dc (Outside the USA: +12 to
24V dc, ±10%). (See UL section below for any applica-
ble UL specifications)
Consumption: Less than 1.4 W (60 mA) at 24V dc
Housing
Polycarbonate housing and rotary dial cover; polyester
labels; EDPM rubber cover gasket; nitrile rubber, non-
sulphur cured button covers
Weight: 0.26 kg (0.57 lbs)
Mounting: #10 or M5 (SS M5 hardware included)
Max. Tightening Torque: 0.56 N·m (5 lbf·in)
Antenna Connection
Ext. Reverse Polarity SMA, 50 Ohms
Max Tightening Torque: 0.45 N·m (4 lbf·in)
Interface
Indicators: Two bi-color LEDs
Buttons: Two
Display: Six character LCD
SureCross DX80 Node
6
