Lens Selection Guide
8
P/N 69950 rev. B
Banner Engineering Corp. • Minneapolis, MN • USA
www.bannerengineering.com • Tel: 763.544.3164
Focal Length Table, Working Distances in Millimeters
FOV in
Millimeters
(H x V)
Working Distances in Millimeters
4 mm
Lens
8 mm
Lens
12 mm
Lens
16 mm
Lens
25 mm
Lens
50 mm
Lens
75 mm
Lens
5 x 4
104*
115*
*
Extensions
may be
added to
these 25- ,
50- ,and
75-mm
lenses as
indicated by
the given
lengths
(in mm) in the
10 x 8
156*
230*
15 x 11
78*
208*
285*
20 x 15
104*
260*
370*
25 x 19
83
130*
313*
425*
30 x 23
75
100
156*
365*
510*
35 x 26
58
88
117
182*
417*
595*
40 x 30
67
100
133
208*
469*
640*
45 x 34
75
113
150
234*
521
696
50 x 38
83
125
167
260*
573
773
60 x 45
50*
100
150
200
313*
677
928
70 x 53
58*
117
175
233
365*
781
1082
80 x 60
67*
133
200
267
417
885
1237
90 x 68
75*
150
225
300
469
990
1392
100 x 75
83*
167
250
333
521
1094
1546
110 x 83
92*
183
275
367
573
1198
1701
120 x 90
100*
200
300
400
625
1302
1856
130 x 98
108
217
325
433
677
1406
2010
140 x 105
117
233
350
467
729
1510
2165
150 x 113
125
250
375
500
781
1615
2320
160 x 120
133
267
400
533
833
1719
2474
170 x 128
142
283
425
567
885
1823
2629
180 x 135
150
300
450
600
938
1927
2783
190 x 143
458
317
475
633
990
2031
2938
200 x 150
167
333
500
667
1042
2135
3093
225 x 169
188
375
563
750
1172
2396
3479
250 x 188
208
417
625
833
1302
2656
3866
275 x 206
229
458
688
917
1432
2917
4253
300 x 225
250
500
750
1000
1563
3177
4639
325 x 244
271
542
813
1083
1693
3438
5026
350 x 263
292
583
875
1167
1823
3698
5412
375 x 281
313
625
938
1250
1953
3958
5799
400 x 300
333
667
1000
1333
2083
4219
6186
425 x 319
354
708
1063
1417
2214
4479
6572
450 x 338
375
750
1125
1500
2344
4740
6959
475 x 356
396
792
1188
1583
2474
5000
7345
500 x 375
417
833
1250
1667
2604
5260
7732
525 x 394
438
875
1313
1750
2734
5521
8119
550 x 413
458
917
1375
1833
2865
5781
8505
575 x 431
479
958
1438
1917
2995
6042
8892
600 x 450
500
1000
1500
2000
3125
6302
9278
625 x 469
521
1042
1563
2083
3255
6563
9665
650 x 488
542
1083
1625
2167
3385
6823
10051
