Specifications
Supply Voltage and Current
Voltage supplied by PresencePLUS P4 sensors, if op-
erating at 24V dc (see sensor manual).
62 x 62 Models: Infrared — 24V dc @ 100 mA max.
80 x 80 Models: 24V dc @ 250 mA max.
All other colors — 24V dc @ 130 mA max.
Connections
300 mm (12") attached pigtail with 3-wire, 8 mm male
Pico-style connector
Construction
Low-carbon steel with black zinc plating, acrylic win-
dow
Light Source
LED, see Models table above for wave lengths
Illumination
High-intensity ring light
Useful Life
10,000 hours (LED ON time). When operated within
specifications, output will decrease less than 30% after
10,000 hours and less than 50% (less than 40% for red
and IR models) after 20,000 hours.
Operating Conditions
Temperature: 0° to +50° C (+32° to 122° F)
Relative humidity: 90% at 50° C (non-condensing)
max.
Cleaning Instructions. Regularly remove any dust, dirt, or fingerprints from the light source.
1. Blow off dust using anti-static compressed air.
2. If necessary, use a lens cloth and lens cleaner or window cleaner to wipe off remaining debris. Do not use any other chemicals for
cleaning.
Dimensions
62 x 62 mm Models
66.1 mm
(2.6")
66.1 mm
(2.6")
33.0 mm
(1.3")
33.0 mm
(1.3")
33.3 mm
(1.31")
2 x Ø 4.4 mm
(2 x Ш 0.17")
ш 42.7 mm
(1.68")
80 x 80 mm Models
87.3 mm
(3.44")
Ø 45.7 mm
(Ø 1.80")
43.6 mm
(1.72")
87.3 mm
(3.44")
42.9 mm
(1.69")
2 x Ø 4.4 mm
(2 x Ø 0.17")
