Gateway with Multiple Nodes (DX80)

In this configuration, the Gateway is the master of the wireless network.

Configure this network using the User Configuration Tool (UCT) and RS-485 to USB adapter cable. The UCT is used to map

inputs and outputs between Nodes and Gateways.

1

2

2

2

Item Model No.

Description

1

DX80G...

DX80 or DX80 Performance Gateway

2

DX80N...

DX80 or DX80 Performance Node

81398

User Configuration Tool (free to download from the

Wireless Products

section of

Banner Engineering's website)

BWA-HW-006

RS-485 to USB adapter cable (not shown)

System Layouts

2
