154 ▪▪▪▪▪▪▪
2
No communication between
Vision and the instrument.
1. Verify that the RJ-45 cable is plugged in at both
the instrument and at the network wall jack.
2. Verify that the RJ-45 cable is plugged in at both
the computer and at the network wall jack.
(NOTE: Direct connection is explained in section
3.0 for non-network users. This requires a
“crossover” cable as supplied.
3. Verify that the instrument is powered on. (See
previous Observed Problem.) Note front-panel LED
indicators.
4. Verify that the network wall jack is active, and has
a connection point within the internal network.
5. Verify that the instrument is Available in Configure,
Input. This instrument serial number is found on
the serial plate on the side of the instrument. This
serial number should be visible in Vision in
Configure, Input.
6. Verify that the connector ends of the RJ-45 cable
are not damaged, crushed, or distorted in any way.
Wires should be firmly clinched by the connectors.
