2 Parts and controls
757 VA Computrace – Hardware
12
42 Stirrer tip (6.1204.090)
43 PTFE tube (6.1819.010)
for optional supply of the waste solution
to gas wash bottle 44 (attached)
44 Gas wash bottle (6.2405.030)
for separating mercury from the waste
solution (attached)
45 PTFE tube (6.1819.010)
for optional siphoning off the waste
solution from gas wash bottle 44
(attached)
46 Dummy cell connection ”WE-D”
differential mode simulation
(peak/wave)
47 Dummy cell connection ”WE-L”
linear mode simulation (RC element)
48 Dummy cell connection ”RE”
49 Dummy cell connection ”AE”
50 Slotted screw for controlling the
tapping power in the DME case
Note: The factory setting should not be
changed without good reason!
