Cut Length – Known Take-Out Value
The Pipe Trades Pro can solve cut lengths for materials and
fittings not currently built into the calculator by entering a known
Take-Out value.
Find the cut length (end-to-end) for a pipe offset with a 10”
Offset and bend angle of 45°. This example assumes 4” Type
40 PVC, with a known Take-Out value of 2 and 3/16 inches.
Note: Override the Welder’s Gap for this example.
KEYSTROKE DISPLAY
  0.
1. Select PVC:
(press until PLAStIC id displayed) PLAStIC
2. Enter Pipe Size:
  
40 SIZE 4 INCH
3. Enter Offset
   
OFST 10 INCH
4. Enter bend angle:
  
/_Ø 45.00°
5. Enter known Take-Out:
       
TO 2-3/16 INCH
6. Enter 0 for Welder’s Gap:
  
GAP 0 INCH
7. Find the pipe cut length:

TRAV 14-1/8 INCH

CUT 9-3/4 INCH

TO 2-3/16 INCH
Continue pressing the
 key to view all related values.
The cut length for the Type 40 PVC pipe is 9 and 3/4 inches
when using 4”, 45° fittings with a user-defined Take-Out value
of 2 and 3/16 inches.
Note: To return the Welder’s Gap to the default 1/8”, press
  to reset your calculator back to default values.
