 (Material)
MATL SIZE StEEL
 (Weight per Foot)
PIPE SIZE 10.2528 LB PER FEET
 (Filled Weight/Foot)
FILL SIZE 13.11634 LB PER FEET
 (Internal Area)
AREA SIZE 6.605199 SQ INCH
Elbow Type
The Elbow Type function lets you chose between long or short
radius, and between factory and field cut 45º Butt Weld (B.W.)
elbow types. The default value is for long radius, factory cut 45º
B.W. elbow type.
The Elbow option setting has an impact on the Take-Out
calculations as the radii vary between long and short Butt Weld
fittings. Additionally, factory made 45º B.W. elbow fittings can
have a different Take-Out calculation from the field cut variants.
This function toggles the Elbow types between the following
options:
Butt Weld – Long
Default. Use this option when utilizing 90° long radius or
factory 45° long radius B.W. elbow fittings, or any odd-angle
long radius fitting cut from a 90° B.W. elbow.
Butt Weld – Short
Use this option when utilizing 90° short radius or factory 45°
short radius fittings, or any odd-angle short radius fitting cut
in the field from a 90° B.W. elbow.
Field Cut – Long
Use this option when utilizing long radius B.W. elbows, or
any odd-angle long radius fitting cut from a 90° B.W. elbow,
including a 45° B.W.
Field Cut – Short
Use this option when utilizing short radius B.W. elbows, or
(cont'd)
(cont'd)
