Chapter 2

Theory of Operation

General

The 8578A100GIG is a high powered, air-cooled, RF load

used for termination of coaxial transmission lines. The RF

energy, when converted into heat, is transmitted directly to

the external area by a forced air system.

RF Section

Description

The RF section of the 8578A100GIG is composed of a paral-

lel combination of tubular resistors. These resistors are

carefully positioned to provide a reduction in surge imped-

ance proportional to the distance along the resistive system,

which finally terminates to the housing forming the return

path for the coaxial circuit. This produces a very uniform

and almost reflectionless line termination over the stated

frequencies of the load resistor.

Heat

Transfer

The resistors used in the 8578A100GIG are of a tubular ce-

ramic type, situated in an angled position within their hous-

ing. When the unit is in operation, externally forced air is

blown into the side grille opening and directed over the RF

resistor network. The heat, developed in the resistors from

dissipation of the RF energy, is carried off by the flow of air

over the resistors surface. The hot air is then exhausted

through the opposite side grille openings in the unit.

Interlock

Control

Circuit

The interlock control circuit provides fail-safe protection of

the transmitter and load resistor in the event of an overload

situation. This protection is necessary because dissipation of

the heat generated by the RF power is critically dependent

upon a required minimum flow of external cooling air at all

times. If the airflow over the resistor array should stop or be

restricted and the temperature in the RF chamber should

rise beyond a safe limit, the heat sensor unit will sense the

change and actuate the interlock relay to reverse the pro-

cess and turn off the transmitter. The interlock system will

not permit re-operation of the transmitter until the air flow

is restored and a safe low temperature in the RF housing is

once again attained.

5
