About This Manual
Sample Model ACM–M–DMNFTL
470 – 960 MHz ACM with male 7/16 input, female N output,
female TNC monitor ports, requiring a low voltage power supply
Note: Exception: Model ACM-L2-DFDFTL-12SP and
ACM-L2-DFDFTH-48SP has no other variations.
Note: Exception: Models in ACM500 series do not support
frequency range L0 and H and any of its variations.
Changes to this Manual
We have made every effort to ensure this manual is accurate. If you
discover any errors, or if you have suggestions for improving this man-
ual, please send your comments to our Solon, Ohio factory. This man-
ual may be periodically updated. When inquiring about updates to
this manual refer to the part number and revision on the title page.
Base
Model Frequency Range
(MHz) RF
Connectors Monitor Port
Connectors Power Supply
Voltage
ACM L0 108 – 138 NM Male N N Female N L +11 to +26 Vdc
ACM
500 L1 136 – 225 NF Female N T Female TNC H ± (36 to 72) Vdc
L2 225 – 520 DM Male 7/16
DIN
B Female BNC
M 470 – 960 DF Female
7/16 DIN
H 960 – 2400
ACM – M – DM NF T L
Frequency
Range
Base
Model
Input Conn.
and Gender Output Conn.
and Gender
Monitor
Port
Conn.
Power
Supply
Voltage
