7
Chapter 3 Installation
This chapter provides information for preparing the Bird Antenna &
Cable Monitor for use.
Unpacking and Inspection
1. Carefully inspect the shipping container for signs of damage.
Note: If damage is noticed, do not unpack the unit. Immedi-
ately notify the shipping carrier and Bird Electronic Corporation.
2. If the shipping container is not damaged, unpack the unit.
Note: Save the packing material in case the unit needs to
be shipped again.
3. Inspect all of the components for visible signs of damage.
Note: Immediately notify the shipping carrier and Bird
Electronic Corporation of equipment damage or missing parts.
The Bird ACM is shipped complete and ready for use upon receipt.
After unpacking and inspecting the unit, it is ready to be installed.
Mounting
Mount the ACM in the feeder line between the combiner and the
antenna. Make sure that the alarm LED and reset button are
accessible, and that the connecting cables have proper clearance.
Cable Connections
When connecting the Bird ACM to RF power, use 50 ohm coaxial cable
suitable for the frequency and power level of operation. The cable
connector should mate with the connector on the unit.
WARNING
Leaking RF energy is a potential health hazard. Never
attempt to connect or disconnect equipment from the
transmission line while RF power is being applied.
Severe burns, electrical shock, or death can occur.
