PROGRAMMING THE BREWER (cont.)

RECIPE PROGRAMING METHODS

There are three methods of programming the vari-

ous brewing parameters of the SINGLE/GPR DBC or

DUAL/GPR DBC with Smart Funnel Brewer.

METHOD 1:

Using a Smart Funnel and a G9-2T DBC or MHG

Grinder:

Certain coffee NAMES are stored in the G9-2T DBC

or MHG's memory. When a particular name of coffee

is ground into the Smart Funnel, that name and the

batch size selected are transferred from the grinder to

the programming chip located in the funnel's handle.

The funnel is then inserted into the brewer's funnel

rails (left side for DUAL brewers). The sensor coil on

the brewer reads the information contained in the

handle. This then allows the operator to set the BREW

VOLUMES, BYPASS PERCENTAGES, PULSE BREW

TIMES, PREINFUSION TIMES and DRIP-OUT TIMES

for that particular coffee NAME. Each coffee NAME

can be set individually to provide optimum brewing

quality.

METHOD 2:

Using a RECIPE CARD to enter all of the brew set-

tings at one time:

If using a coffee name not in the grinder's memory,

the customer can obtain a RECIPE CARD from the

factory with all the information needed to set up that

particular coffee name. This includes the COFFEE

NAME, BREW VOLUMES, BYPASS PERCENTAGES,

PULSE BREW TIMES, PREINFUSION TIMES, and

DRIP-OUT TIMES.

METHOD 3:

Not using a Smart Funnel and/or a G9-2T DBC or

MHG Grinder:

This allows the operator to enter ONE set of brew-

ing parameters (for each side on DUAL brewers),

in the event a Smart Funnel and/or a G9-2T DBC or

MHG is not used with the SINGLE/DUAL/GPR Brewer.

This is referred to as a NO NAME coffee flavor. If the

brewer does not read the information in the funnel's

handle, it automatically selects the NO NAME brew-

ing parameters set up prior to brewing. This includes

BREW VOLUMES, BYPASS PERCENTAGES, PULSE

BREW TIMES, PREINFUSION TIMES and DRIP-OUT

TIMES for the three batch sizes.

ARE YOU CREATING OR CHANGING A RECIPE FOR A

COFFEE NAME PREVIOUSLY USED IN THIS BREWER?

REFER TO NAME LIST

IN GRINDER MANUAL

CONTACT BUNN-O-MATIC

FOR ASSISTANCE

GO TO REVIEW RECIPES

AND FOLLOW INSTRUCTIONS

TO VIEW A LIST OF EXISTING RECIPES,

GO TO REVIEW RECIPES

AND FOLLOW THE INSTRUCTIONS

GO TO SET NEW RECIPE,

AND FOLLOW THE

INSTRUCTIONS

YOU WILL ENTER NO

NAME BREW SETTINGS

FOR SINGLE BREWERS,

NO NAME LEFT AND NO

NAME RIGHT BREW

SETTINGS FOR DUAL

BREWERS

YOU WILL MODIFY AN

EXISTING RECIPE

DOES THE GRINDER HAVE THE

NAME IN ITS MEMORY?

FOLLOW INSTRUCTIONS

ON THE RECIPE CARD

HAVE YOU RECEIVED A RECIPE CARD

CONTAINING THE NEW RECIPE?

DON'T KNOW

YES

DON'T

KNOW

RECIPES

This diagram allows for the creating, modifying,

or viewing of recipes in the brewer.

P2369-1

41343 080108
