Page 16
MUST GRIND INTO
FUNNEL FIRST
(COFFEE NAME)
SETUP COMPLETE
BEGIN SETUP OF
(COFFEE NAME)
QUIT SETUP?
YES
USE LEFT SIDE
ONLY
INSERT FUNNEL
WITH NEW NAME
REVIEW RECIPES?
NO YES
(COFFEE NAME)
NO YES
3 BATCHES DONE?
NO YES
SET NEW RECIPE?
NO YES
2 SEC.
CYCLES THROUGH
THREE SCREENS
2 SEC.
FUNNEL
CONTAINS NAME
FUNNEL CONTAINS
NO NAME
SETUP BREW VOLUMES, BYPASS,
PULSE BREW, PREINFUSION, DRIPOUT TIME
SEE SEPARATE DIAGRAMS
FOR SETUP INSTRUCTIONS
FUNNEL DETECTED
P2299-1
SET NEW RECIPE
Using a Smart Funnel and a G9-2T DBC or MHG
Grinder:
This function allows the operator to set BREW
VOLUMES, BYPASS PERCENTAGES, PULSE BREW
TIMES, and DRIP-OUT TIMES for each coffee name
preset in the grinder's memory.
Certain coffee NAMES are stored in the Grinder's
memory. When a particular name of coffee is ground
into the Smart Funnel, that name and the batch size
selected are transferred from the grinder to the
programming chip located in the funnel handle. The
funnel is then inserted into the brewer's funnel rails
(left side on DUAL brewers). The sensor coil on the
brewer reads the information contained in the handle.
The name of the coffee flavor will then appear on the
display. This then allows the operator to set the BREW
VOLUMES, BYPASS PERCENTAGES, PULSE BREW
TIMES, and DRIP-OUT TIMES for that particular coffee
NAME. It also allows the operator to set other brewing
parameters, such as BREW TEMPERATURE, READY
TEMPERATURE, BREW LOCKOUTS, etc. Each coffee
NAME can be set individually to provide optimum
brewing quality.
PROGRAMMING THE BREWER (cont.)
Procedure for Setting the Recipe:
NOTE: Before beginning setup, place a server beneath
the brew funnel (left side on DUAL brewers).
1. Insert the funnel into the grinder and select a batch
size to grind. It is not necessary to have coffee
beans in the hopper(s) in order to program the
brewer. The coffee name is pre-selected and stored
in the grinder's memory (for side being ground
on DUAL brewers).
2. Press the GRIND switch. When the grinder stops
grinding, remove the funnel.
3. On the brewer, press and hold the upper right
hidden switch (®) until the display reads UNITS.
Release the switch, then press switch again until
display reads SET NEW RECIPE.
4. Press and release YES. The display should read
INSERT FUNNEL WITH NEW NAME, then USE LEFT
SIDE ONLY on DUAL brewers only, and finally, QUIT
SETUP? These displays will repeatedly cycle.
5. Insert the funnel into the rails of the brewer (left
side on DUAL brewers). The display should read
the NAME of the coffee that was ground into the
funnel, along with a NO and YES. If the NAME on
the display is correct, press YES.
6. If, for some reason, the name of the coffee from
the grinder did not load properly into the funnel,
or if a grind has not yet been done, the display will
read MUST GRIND INTO FUNNEL FIRST. It will be
necessary to grind another batch following steps
1 and 2.
7. If the grind is acknowledged by the brewer, the
display will read BEGIN SETUP OF (COFFEE NAME).
Then the screen will display BREW OZ. and a batch
light will be blinking. (Refer to BREW OZ (SETTING
OR ADJUSTING for description)
BREW OZ. XX.X
(-) DONE (+)
% BYPASS XX.X
(-) DONE (+)
3 BATCHES DONE?
NO YES
P2415
DUAL
BREWERS
only
41343 080108
