Page 18
SET NEW RECIPES (cont.)
PROGRAMMING THE BREWER (cont.)
SET NEW RECIPE:
Using a RECIPE CARD to load coffee names and
brew settings into the Single/Dual GPR-DBC with
Smart Funnel:
The G9-2T DBC or MHG's memory contains certain
coffee names. If the operator uses a coffee name that is
not already stored in the grinder's memory, a RECIPE
CARD can be obtained from the factory. The RECIPE
CARD would include all the information needed to set
up that particular coffee name. The information from
the RECIPE CARD is loaded into the grinder's memory,
then into the brewer's memory by holding the chip
area up to the equipment's sensing coil. This informa-
tion can include the coffee name, BREW VOLUMES,
BYPASS PERCENTAGES, PULSE BREW TIMES, and
DRIP-OUT TIMES for that particular coffee NAME.
These can all be loaded in seconds.
Contact Bunn-O-Matic Corporation for the avail-
ability of RECIPE CARDS.
NOTE: Instructions to program the brewer and grinder
are printed on the RECIPE CARD, along with the coffee
name that is being programmed.
Procedure to program the coffee name:
1. Remove the funnels (if present) from the funnel
rails (both sides on DUAL brewers).
2. Position the RECIPE CARD vertically, so that the
top end of the chip is beneath the funnel sensing
coil (left side on DUAL brewers).
3. After a short pause the display will read CARD CON-
TAINS RECIPE FOR then will change to (COFFEE
NAME) SHOW QUIT SAVE. All brewing parameters
for that coffee name are now transferred from the
CARD to the brewer.
4. To show (view) this information, press and release
SHOW. The display will scroll through all of the
brew settings for all three batch sizes. The display
will then return to CARD CONTAINS RECIPE FOR
then will change to (COFFEE NAME) SHOW QUIT
SAVE.
5. If all brew settings are correct, press SAVE. The
display will read (COFFEE NAME) SETUP COM-
PLETE. All brew settings for that name are now
stored in the brewer's memory.
6. If the brewing information is not correct, or it is
desired to exit the setup before the settings are
loaded into the brewer's memory, press QUIT. The
display will read (COFFEE NAME) NOT SAVED. The
display will then return to the MAIN SCREEN.
POSITION CARD UNDER THE
SENSOR COIL
(left side on DUAL brewers)
READY TO BREW
WATER TEMP: 200°
CARD CONTAINS
RECIPE FOR
(COFFEE NAME)
SHOW QUIT SAVE
(COFFEE NAME)
SETUP COMPLETE
(COFFEE NAME)
NOT SAVED
SCROLLS THROUGH ALL
OF THE BREW SETTINGS
FOR THE THREE BATCH
SIZES FOR THAT COFFEE
NAME
41343 080108
