Bunn DUAL GPR-DBC WITH SMART FUNNEL 41343 - Manual (Page 22)

Page 22
PROGRAMMING FUNCTIONS - (cont.)
% BYPASS
This function allows adjustment of the amount of
water that bypasses the grounds. The number signi-
fies the percentage of the brew volume which does
not flow over the coffee grounds.
Modifying recipes - bypass percentages:
Range: 0% to 90% for all three batch sizes
NOTE: If the brewer is already in the % BYPASS screen,
it is not necessary to follow steps 1 through 6 in this
section, but proceed directly to step 7.
1. Press and hold the upper right hidden switch (®)
until the display reads UNITS. Release the switch,
then press and release the switch until the display
reads REVIEW RECIPES.
2. Press YES to proceed. The display should now
read:
NO NAME, along with MODIFY, SHOW and NEXT
(SINGLE brewers)
NO-NAME LEFT, along with MODIFY, SHOW and
NEXT (DUAL brewers).
3. Press and release NEXT to advance to the desired
coffee name to be modified.
4. Press and release MODIFY. The display should
read BREW OZ.
5. Press and release DONE. The display should read
3 BATCHES DONE?.
6. Press and release YES. The display should now
read % BYPASS, and a batch light will be blinking.
Press and release the batch size to be modified.
7. Using (-) and (+) set the amount of bypass water
(percentage) to be dispensed around the grounds
for that particular batch size.
8. When finished, press another batch size and repeat
step 7 for each batch to be modified.
9. When finished setting all batch sizes, press DONE.
The display should read 3 BATCHES DONE?
10. If they are not correct, press and release NO to
return to the % BYPASS setup screen.
11. If the 3 batch sizes are correct, press YES. This will
advance to SET PULSE BREW. Another alternative
is to press the ON/OFF switch (either on DUAL
brewers) to exit % BYPASS setup and return to
the MAIN SCREEN.
REVIEW RECIPES?
NO YES
EXIT TO
NEXT FUNCTION
SCREEN
NO-NAME LEFT
MODIFY SHOW NEXT
NO-NAME
MODIFY SHOW NEXT
DUAL
BREWERS
SINGLE
BREWERS
BREW OZ. XX.X
(-) DONE (+)
3 BATCHES DONE?
NO YES
% BYPASSS XX.X
(-) DONE (+)
SEE MODIFYING
PULSE BREW ON
THE FOLLOWING PAGE
OR PRESS AND RELEASE
ON/OFF SWITCH TO EXIT THE
% BYPASS SETUP AND RETURN
TO THE MAIN SCREEN
(COFFEE NAME)
MODIFY SHOW NEXT
THAT WAS THE
LAST RECIPE
WHEN THE LAST COFFEE
NAME IN BREWER'S MEMORY
IS DISPLAYED, PRESSING
NEXT WILL EXIT AND THE
DISPLAY WILL THEN READ:
ADVANCES TO ALL OTHER
COFFEE NAMES PROGRAMMED
IN THE BREWER"S MEMORY
3 BATCHES DONE?
NO YES
SET PULSE BREW?
NO YES
41343 080108
