Autocue SSP-iPad User Manual

Page 7

SSP-iPadUserManual.docx 2011-06-14

11. Adjust the position of the pillars to align with the screw holes of the camera

mounting plate.

12. Re-attach camera mounting plate



if the camera is to be at the lowest level use the four thumbscrews



if the camera is to be in one of the raised positions, use the countersunk screws

to attach the plate to the tops of the mounting plate pillars

Attach camera to mounting plate

13. Use either the supplied ⅜" or ¼" mounting screw to attach your camera to the

mounting plate. You can place the screw through any of the slots in the camera

mounting plate depending on the camera you are using. Ideally the camera lens

should be close to the mirrored glass.

Note: If necessary, you can adjust the position of the whole unit forwards or backwards so

that it is balanced on your tripod.
