Autocue SSP-iPad User Manual

Page 10

SSP-iPadUserManual.docx 2011-06-14

when rearranging the components of your prompter into the different configurations described in the

following sections.

Straight read (Monitor above the camera with no mirror)

The most common situation for using a straight read monitor is in conjunction with a light-ring for chromakey

filming.

N E E D E Q U I V A L E N T P H O T O O F i P a d / T a b l e t P C A N D A D A P T O R

1. Mount the prompter unit to the tripod head.
2. Remove the hood and mirrored glass.
3. Remove the monitor.
4. Change the monitor mounting plate

Note: As illustrated, your iPad or tablet PC must be attached in „portrait‟ orientation.

5. Align the holes in the edge of the mounting plate with the slide nuts in the edge of

the vertical frame

6. Loosely screw in four thumb screws
7. Adjust the position of the monitor by sliding it up and down the vertical frame
