N E E D E Q U I V A L E N T P H O T O O F i P a d / T a b l e t P C A N D A D A P T O R
8. Secure in place by tightening the four thumbscrews.
Prepare camera mount
9. Remove the camera mounting plate.
Adjust camera mount height
Depending on the size of your camera you may need to use the supplied pillars to raise the camera
mounting plate. The smallest cameras will most likely need the longest pillars. Larger cameras require either
no pillars or the shortest ones.
Combine raising the camera with adjusting the position of the hood so that the camera lens is centred in the
mirrored glass.
10. Screw in the appropriate length pillars that raise the plate to the required height for
your camera.
