65 FS1 Installation and Operation Manual — 40.1 Freeze Output
40.1 Freeze Output
This parameter tells the FS1 to freeze the current video frame on all outputs. This may
be useful either for testing or in case of loss of the input source.
Note: The freeze feature can be controlled not only by the front-panel and web
browser interface, but also by a GPI input. When a GPI input is causing the freeze
condition, the AUX lamp will be lit on the front-panel.
41.2 Video SG
This parameter determines the video test signal output from the FS1’s internal test
signal generator. The parameter is used with parameter 41.1 to determine the type of
video test signal output by the FS1.
41.3 Audio SG
This parameter determines the audio signal output from the FS1’s internal test signal
generator.
40.1 Freeze Output Description of Choices
Parameter Adjustments:
Off (Default)
On
Normal operation. The FS1 outputs video from the input.
The FS1 captures and freezes the most current video frame and displays it on the
outputs as long as this parameter is set to On.
41.2 Video SG Description of Choices
Video Test Signal:
OFF (default)
Black
75% Bars
100% Bars
Select the video test signal output:
Turn test signal output OFF.
Video test signal output is color black.
Video test signal output is 75% color bars. This 75% amplitude,100% saturation
test signal is useful to check low frequency response and video tilt as well as the
performance of video clamping.
Video test signal output is 100% color bars. This 100% white full field bars test
signal is helpful to check chroma amplitude versus overall video level.
41.3 Audio SG Description of Choices
Video Test Signal:
OFF (default)
Silence
1 kHz
Select the audio test signal output:
Turn audio test signal output OFF.
Output an audio test signal containing silence only.
Output a standard 1 kHz test signal tone.
