35 FS1 Installation and Operation Manual — 1.1 Output Format
1.1 Output Format
This parameter defines the SDI 1 output format. Depending on other settings, it may
also apply to SDI 2 and the Component Video output.
Notes:
1. Available rates that listed here depend on what has been chosen in the 3.3
Frame Rates parameter setting.
2. If the parameter 1.1 Output Format is set to Follow Ref, and the 6.1 Genlock
Source is set to Input, and the 2.1 Video Input is set to select one of the analog
inputs, then the output format will follow the input format rather than the
format of the signal on the Ref BNC as might be expected. (This combination
of settings effectively disconnects the Ref BNC.)
3. Changing the Output Format selection automatically selects new values for
H & V timing parameters (6.2 Output Timing H, 6.3 Output Timing and
6.4 Analog Output Fine). Each Output Format selection remembers its own H
& V timing settings.
1.2 SDI 2 Out Format
This parameter defines the output format on the SDI 2 BNC connector.
Notes:
1. The output from Downconverter 2 (see block diagram in Chapter 1) is always
standard definition.
2. Bypass mode is not offered in these cases (3:2 Pulldown):
1080pSF/23.98 Input / 1080i/59.94 Output
1080pSF/23.98 Input / 525i/59.94 Output
1080pSF/24 Input / 1080i/60 Output
In these cases, Bypass mode behaves like Normal mode—the output is the
same format as the main SDI1 output.
1.1 Output Format Description of Choices
Parameter Adjustments:
Follow Input (Default)
Follow Ref
SD
HD 720p
HD 1080i
HD 1080psf
Follow the format of the selected input.
Follow the format of the reference video input (Ref).
Select standard definition (available SD rates are listed choices).
Select HD 720p (available rates are listed choices).
Select HD 1080i (available rates are listed choices).
Select HD 1080psf (available rates are listed choices).
1.2 SDI 2 Output Format Description of Choices
Parameter Adjustments:
Normal (Default)
Bypass (Follow Input)
Standard Def
SDI 2 output follows the 1.1 Output Format parameter selection (both SDI outputs
are the same format).
SDI 2 output follows the format of the selected input.
The output from Downconverter 2 (see block diagram in Chapter 1) is always
standard definition.
