6

SD3000 PLUS DC Drive Regulator

Note: Refer to part drawing for additional cable lengths.

DRIVE I/O – 120VAC Drive Command /
Control Inputs

• RPI – Run Permissive Input

• MCR – Output to control M Contactor

• Auxiliary Input 1 – M Contactor feedback

• Auxiliary Input 2 – Inverting fault circuit

breaker (if circuit breaker is used)

• Auxiliary Input 3 – Power module thermal

interlock

• Auxiliary Input 4 – Motor thermal switch

• Auxiliary Input 5 – (spare)

Cable, Drive I/O, DIN TB

• SD3K-CBLDRVIO060 – 5 foot length

• SD3K-CBLDRVIO096 – 8 foot length

(97305700 to view drawing for additional lengths)

EXT GATE P/S – External Gate Power
Supply

External Gate 48V Power Supply

Contact Development for interlocking
guidelines

18 AWG minimum, twisted pair, 2 twists per inch

FWD GATES – Armature Forward Gates Four forward gate outputs to provide gate

signals for up to four power modules

All four outputs are identical

Cable, “Round Style” Connector, Fwd Gates

• SD3K-CBLFWDPM060 – 5 foot length

• SD3K-CBLFWDPM120 – 10 foot length

• SD3K-CBLFWDPM180 – 15 foot length

• SD3K-CBLFWDPM240 – 20 foot length

(97305100 to view drawing for additional lengths)

REV GATES - Armature Reverse Gates

Four reverse gate outputs to provide gate
signals for up to four power modules.
All four outputs are identical

Cable, “Round Style” Connector, Rev Gates

• SD3K-CBLREVPM060 – 5 foot length

• SD3K-CBLREVPM120 – 10 foot length

• SD3K-CBLREVPM180 – 15 foot length

• SD3K-CBLREVPM240 – 20 foot length

(97305300 to view drawing for additional lengths)

120VAC – Power input to regulator

Cabinet control power

10-14 AWG

No.

Description

Connects to

Use Cable Number

7

8

9

10

11
