Dimensions – Rockwell Automation SD3000 PLUS DC Drive Regulator User Manual
Page 3
SD3000 PLUS DC Drive Regulator
3
Dimensions
Dimensions are in inches and (millimeters).
Important: Allow at least 4.5 inches (114.3 mm) for connectors and cable
bend radius in front of unit.
3.25
(82.55)
11.63
(295.40)
5.25
(133.35)
1.03
(26.162)
11.09
(281.686)
0.31
(7.874)
10.06
(255.524)
12.01
(305.054)
12.98
(329.692)
Weight kg (lbs.)
Drive Regulator
Drive Regulator & Packaging
7.03 (15.5)
7.71 (17.0)
