4 SD3000 PLUS DC Drive Regulator
Connecting Power Wiring
and Grounding
Table 1.A Terminal Specifications
GP
COM OK
FDBK OK
LP
P.M. FLT
RPI
OK
EXT. FLT
XMT
RCV
L1
L2
MCR
AUX IN 1
AUX IN 2
AUX IN 3
AUX IN 4
AUX IN 5
AUX OUT
FWD - GATES
REV - GATES
120VAC
EXT GATE P/S
FUSE TYPE
250VAC
3AG 7A
RESOLVER
FEEDBACK
DRIVE
I/O
METER
PORTS
ARM
FDBK
FIELD
PLUS DRIVE CONTROL
Engineered by
SD3000
1
2
3
4
No. Name Description
Part Number for Customer Plug
(provided with SD3000 PLUS) Wire Size Range Torque
Maximum Minimum Recommended
Input Power
Terminal Block
L1, L2, Ground Input power 94809302 4.0 mm 2
(10 AWG)
2.5 mm 2
(14 AWG)
0.677909 N-m
(6 lb.-in.)
Ground Stud Chassis Ground Use grounding cable kit 97297501 provided with regulator
External Gate
Power Supply External Gate
Power Supply
(if used) 94809301 10 AWG,
Twisted Pair,
2 Twists / in. 18 AWG,
Twisted Pair,
2 Twists / in. 0.677909 N-m
(6 lb.-in.)
Meter Ports Meter Port Output 49455-115H 14 AWG,
Twisted Pair,
2 Twists / in.
13feet (4m)
max. length 22 AWG,
Twisted Pair,
2 Twists / in.
13feet (4m)
max. length 0.677909 N-m
(6 lb.-in.)
1
2
3
4
