PowerFlex® 700S and 700H Frame 14 Replacement Power Structures
ASIC Feedback Board Connections - Power Structure #1
ASIC Feedback Board Connections - Power Structure #2
Power Supply Voltage Feedback Board Connections
Connect this component :
termination point . . .
to this component : termination point
ASIC Feedback Board: H903
Star Coupler Fiber Optic Interface Board: J28
Connect this component :
termination point . . .
to this component : termination point
ASIC Feedback Board: H903
Star Coupler Fiber Optic Interface Board: J27
Connect this component :
termination point . . .
to this component : termination point
Power Supply Voltage Feedback
Board: J8
Common Mode Filter Board: J5
Power Supply Voltage Feedback
Board: J5
(fiber optic connector)
Star Coupler Fiber Optic Interface Board: J7
Power Supply Voltage Feedback
Board: J4
(fiber optic connector)
Star Coupler Fiber Optic Interface Board: J6
