TL-Series Servo Motors 15
Publication TL-IN003A-EN-P — June 2007
NEMA Mount Dimensions, Approx.
1 Tolerance for this dimension is: TLY-A1xx -0.009 (-0.0004); TLY-A2xx -0.011 (-0.0004); TLY-A25xx -0.011 (-0.0004).
2 TLY-A120, or TLY-A130 motor with brake, add 35.6 mm (1.40 in.) to L, LB, and LE.
TLY-A220, or TLY-A230 motor with brake, add 34.6 mm (1.36 in.) to L, LB, and LE.
TLY-A2530, or TLY-A2540 motor with brake, add 36.6 mm (1.44 in.) to L, LB, and LE.
3 Tolerance for this dimension is: ±1.0 mm (±0.039 in.).
Motor
Series
TLY-A
AC
mm
(in.)
AD
mm
(in.)
BE
mm
(in.)
D
1
mm
(in.)
HD
mm
(in.)
L
2
mm
(in.)
L-LB
3
mm
(in.)
LA
mm
(in.)
LB
2
mm
(in.)
LE
2
mm
(in.)
M
mm
(in.)
120
—
31.10
(1.22) 21.0
(0.83)
6.35
(0.25)
52.0
(2.05)
91.5
(3.603)
27.0
(1.063)
5.0
(0.20)
64.5
(2.54)
39.1
(1.54)
43.8
(1.725)
130
105.5
(4.153)
78.5
(3.09)
220
60
(2.36)
43.0
(1.69)
27.6
(1.09)
12.70
(0.50) 73.0
(2.87)
137.9
(5.43)
38.1
(1.50)
6.0
(0.24)
99.8
(3.93)
43.3
(1.70)
66.7
(2.625)
230
159.9
(6.30) 121.8
(4.80)
2530
—
53.0
(2.09)
15.875
(0.625) 96.0
(3.78)
149.2
(5.872)
44.5
(1.752)
8.0
(0.32)
104.7
(4.12)
43.8
(1.72)
98.4
(3.875)
2540
158.2
(6.205)
113.7
(4.48)
NEMA motor flanges and shafts are designed to inch dimensions. Other frame areas are designed to metric dimensions.
Conversions are mathematically calculated.
