14 TL-Series Servo Motors
Publication TL-IN003A-EN-P — June 2007
Metric Frame Dimensions, Approx. (cont.)
4 Tolerance for this dimension is: TLY-A1xx -0.021 mm (-0.0008 in.); TLY-A2xx -0.025 mm (-0.001 in.); TLY-A25xx -0.03 mm (-0.0012 in.);
TLY-A310 -0.03 mm (-0.0012 in.).
5 TLY-A1xx has two mounting holes, TLY-A2xx…TLY-A310 have four mounting holes.
Mounting holes are S diameter on M diameter bolt circle.
6 Tolerance for cable length is ±50.0 mm (±1.97 in.). Minimum bend radius is 15.00 mm (0.59 in.).
7 Tolerance for this dimension is: -0.20 mm (-0.008 in.).
8 Tolerance for this dimension is: TLY-A1xx -0.006…-0.031 mm (-0.0002…-0.0012 in.); TLY-A2xx, TLY-A25xx and TLY-A3xx
-0.012…-0.042 mm (-0.0005…-0.0017 in.).
9 X-Y tolerance for this dimension is: TLY-A1xx -0.025 mm (-0.001 in.); TLY-A2xx, TLY-A25xx and TLY-A3xx -0.03 mm (-0.0012 in.). Length
is untoleranced.
Motor
Series
TLY-A
N
4
mm
(in.)
NB
mm
(in.)
P
mm
(in.)
S
5
mm
(in.)
T
mm
(in.)
TB
mm
(in.)
CAB
6
mm
(in.)
G
7
mm
(in.)
F
8
mm
(in.)
Key
9
mm
(in.)
110
30.0
(1.1811)
20.0
(0.79)
40.0
(1.57)
4.5
(0.177)
2.5
(0.10)
4.5
(0.18)
1000
(39.4)
6.2
(0.244)
3.0
(0.118)
3 x 3 x 15
(0.118 x 0.118 x
0.59)
120
130
220
50.0
(1.9685)
27.0
(1.06)
60.0
(2.36)
5.5
(0.217)
3.0
(0.12)
7.0
(0.28)
9.5
(0.374)
4.0
(0.157)
4 x 4 x 15
(0.158 x 0.158 x
0.59)
230
2530
70.0
(2.7556)
34.0
(1.34)
80.0
(3.15)
6.6
(0.260)
13.0
(0.512)
5.0
(0.197)
5 x 5 x 20
(0.197 x 0.197 x
0.79)
2540
310
80.0
(3.15)
86.0
(3.39)
Metric motor frames are designed to metric dimensions. Inch dimensions are a mathematical conversion.
